Product information

Description

ABUS Secoris > reliably protects homes, offices and commercial properties. Top protection, flexibly expandable The ABUS alarm system offers comprehensive protection against burglary and glass breakage, as well as fire alarms. Water damage and emergencies. The system is also suitable for larger buildings and can accommodate up to 200 detector groups. expandable. It offers The ESEZ60500 offers state-of-the-art security features, such as the integration of up to to 50 BUS components, the... Read more

Details

Certification: EN 50131 Grade 2
Communication/Alerting: Alarm receiving center, voice, SMS, e-mail, push notification
Compatible with: Apple HomeKit, wAppLoxx
Connections: L/N socket, RJ45 (LAN), SATA 3.0 connector, SIM card slot (Nano-SIM), Micro-SD card slot, 4 detector zone inputs, 1 relay output, 1 BUS interface (RS485)
Wireless networked: Yes
Dimensions (WxHxD): 242 x 190 x 45 mm
Display: Status LED (power, internet, communication), ABUS logo (system status)
Duplex antenna technology: Yes
Emergency power supply: Li-ion battery 7.4V / 6,000mAh
Environmental class: II
Event log: Yes
Standard: EN 50131-1+A3:2020, EN 50131-3:2009, EN 50131-5-3:2017
Gross weight: 0.95 kg
PSTI compliance required: Yes
PSTI compliance provided: No
Integrated siren: No
Housing material: ABS
Operating temperature: -10°C to +40°C
Max. humidity: 85%
Wireless frequency: 868 MHz
Max. emergency power runtime: 12 hrs
Max. number of BUS components: 2
Max. range transmit/receive: 1,000 m
Modulation: 2FSK
Network connection Ethernet: 1 GbE LAN SSL/TLS
Network protocols: HTTPS
Number of components: 160
Number of events: 10,000
Number of users: 50
Number of wired zones: 4 (2CC/EOL/DEOL)
Number of partitions/monitoring areas: 40
Operation: App
Outputs: 1 relay output (NC/COM/NO)
Programming: Via web server or app
Protocols for alarm receiving centers: SIA-DC09
Wireless power: 25 mW
Remote maintenance: Yes
Tamper monitoring: Yes
VdS class: none
Video channels IP: 8
Video verification: integrated NVR (24/7 recording with hard drive), event-driven recording (Micro-SD card)
Voltage monitoring: Yes
External interface: Yes

Scope of delivery

1x Comfion Pro burglar alarm control panel
1x battery pack
1x opening tool
1x wall bracket
2x wired detector connection cable

Downloads

📄 Kurzanleitung

📄 Installationsanleitung

📄 Bedienungsanleitung
